Automated Robot Gripping Replacement Fittings for Packaging & Sheet Handling Production Lines, Wear-resistant Nitrile & Silicone Single Layer PA-60 PF-60 PF-80 PFG-95 Pneumatic Vacuum Suction Cup With Connector

First, check the suction cup before installation, confirm the rubber body and integrated connector are intact without cracks, deformation or aging damage, and select silicone or nitrile material and corresponding size according to actual working environment and workpiece type. Second, clean the robotic arm mounting interface and workpiece surface thoroughly to remove dust, oil stains and sundries, ensuring clean and smooth contact surfaces for stable vacuum sealing. Third, connect the integrated suction cup joint firmly to the pneumatic fixture port, confirm the connection is tight and stable to avoid air leakage during operation. Fourth, turn on the vacuum air source and conduct air tightness test, check the cup edge and connector for air leakage, and adjust the vacuum pressure to a suitable working range. Fifth, perform trial gripping on flat workpieces such as cartons and plastic sheets, verify the suction force is stable and the workpiece is gripped evenly without shaking or falling off. Sixth, after successful trial operation, start formal automated picking, placing and handling work. For daily maintenance, regularly clean dirt and residual dust on the suction cup surface, inspect rubber wear and aging conditions periodically, and replace the suction cup timely if suction attenuation or sealing failure occurs to ensure stable and continuous operation of automation equipment.
