T-type Exhaust Large Flow Split Gas Path Pneumatic Gas Distribution Block Straight-Through Multi-Pipeline Compact Exhaust Valve

Product Name	Multi‑port Pneumatic T‑valve Manifold	Body Material	High‑Quality Aluminum Alloy
Surface Treatment	Anodized Anti‑Corrosion	Structure Type	Multi‑port T‑type Air Channel Structure
Load Capacity	30kg Load‑Bearing Capacity	Ventilation Feature	Large Ventilation Volume, Stable Airflow
Installation Feature	Flexible Combination & Easy Installation	Product Advantage	Durable, Corrosion‑Resistant, Pipeline Simplification
Application	Pneumatic System, Automation Equipment, Air Compressor	Customization	Non‑Standard Hole Quantity & Size Customizable
Supply Mode	Factory Direct Sales	Origin	Made in China

Inquiry Contact Us

Description

Is there a problem? Please contact us to serve you!

+86-18015634179

[email protected]

Inquiry

Detail Information

who are we?	We are based in Jiangsu, China, start from 2007,sell to North America(50.00%),Domestic Market(10.00%),South Asia(5.00%),South America(5.00%),Oceania(5.00%),Western Europe(5.00%),Eastern Asia(5.00%),Eastern Europe(5.00%),Mid East(5.00%),Southeast Asia(5.00%). There are total about 5-10 people in our office.
how can we guarantee quality?	Always a pre-production sample before mass production; Always final Inspection before shipment;
why should you buy from us not from other suppliers?	We have 20 years of design and research experience, focusing on various automatic mechanical equipment accessories, electromechanical equipment accessories, such as vacuum suction cups, hardware brackets, pneumatic components, silicone products, rubber pro

Description

Service items	Description
Packaging	Export-grade standard packaging, moisture-proof and shockproof
Delivery	Ample inventory
Custom packages	Customized packaging is provided according to customer requirements
After-sales service	Professional technical support and after-sales service
Customization	We provide OEM and ODM customized services for buyers worldwide

Product Description

This multi‑port pneumatic T‑valve manifold is an aluminum‑made air distribution block for pneumatic systems. It features large ventilation volume and 30kg load‑bearing capacity, supporting flexible combination and easy installation. Durable and corrosion‑resistant, it is widely used for air flow distribution in automation equipment. Non‑standard customization is available with factory direct sales and bulk discounts.

Core Selling Points

Large ventilation volume & high load capacity
Supports 30kg load‑bearing with smooth air flow, ensuring stable pneumatic system operation.
Flexible combination & easy installation
Modular design allows free assembly, quick mounting and connection for different pipeline layouts.
Premium aluminum material
Lightweight, rust‑proof, wear‑resistant and long‑lasting for continuous industrial use.
Multi‑port distribution design
Centralizes air supply, simplifies pipelines and improves pneumatic control efficiency.
Customizable service
Non‑standard hole quantity, size and spacing can be customized to meet special application needs.

Detailed Features

Material: High‑quality aluminum alloy, anodized surface for anti‑corrosion
Structure: Multi‑port manifold block with T‑type air channels
Load Capacity: 30kg
Air Flow: Large ventilation volume for stable gas transmission
Application: Pneumatic automation systems, air compressors, mechanical equipment, pipeline distribution
